# Show limitation in old (prior to version 6) igamma domain and convergence
#
save_encoding = GPVAL_ENCODING
set encoding utf8

set title "igamma domain and convergence improved in version 6"

set label 1 at graph 0.1, 0.8
set label 1 "igamma(a,z) = {Γ^{-1}(a) {/*2 ∫@_{/*0.5 0}^{/*.5 z}} {/:Italic t^{a-1}e^{-t}dt}"

set sample 1000
set xrange [.99 : 1.01]
set yrange [0:1]
set tics nomirror
set border 3 lt 0
set key bottom
set tics tc rgb "black"
set ytics 1

plot for [N=1:9] igamma( 10.**N, x*10.**N ) lw 2 \
         title sprintf("igamma( 10^{%d}, x*10^{%d})",N,N)


Click here for minimal script to generate this plot

#
# Previous igamma algorithm fails to converge for large a
#
set title "igamma domain and convergence improved in version 6"
set border -1 front linewidth 1.000
set view 46, 16, 1, 1
set samples 201, 201
set isosamples 201, 201
set style data lines
set xyplane relative 0
set xlabel "a"
set xrange [ 0.00000 : 3000.00 ]
set ylabel "x"
set yrange [ 0.00000 : 3000.00 ]
set zrange [ * : * ]

splot igamma(x,y) lw .1


Click here for minimal script to generate this plot

set encoding save_encoding
