gnuplot demo script: textbox.dem

autogenerated by webify.pl on Thu Nov 15 12:12:43 2018
gnuplot version gnuplot 5.2 patchlevel 5
set grid
unset xtics
set xrange [ -0.50 : 12.00 ]
set yrange [ 30.00 : 110.0 ]
unset ylabel
set bmargin  3
unset key

set multiplot layout 1,2

set style textbox opaque border lc "blue"
set title "textboxes with blue border"
plot 'table.dat' using 0:2 title column with lines lw 3,  \
     ''          using 0:2:2 with labels center boxed notitle column

set style textbox opaque margins 6,1.5 fc "grey75" border lc black
set title "larger textboxes with grey fill"
replot

unset multiplot
