gnuplot demo script: binary.dem

autogenerated by webify.pl on Sat Mar 11 15:38:13 2023
gnuplot version gnuplot 5.4 patchlevel 7alpha
set style data lines
set hidden3d
set title "Hidden line removal of explicit binary surfaces"
set ticslevel 0
set key box

set xrange [-3:3]
set yrange [-2:2]
splot "binary1" binary

Click here for minimal script to generate this plot




set view 70,45
set xrange [-3:3]
set yrange [-3:3]
splot "binary2" binary

Click here for minimal script to generate this plot




set title "Notice that sampling rate can change"
set vi 70,10
set xrange [-3:6]
set yrange [-3:6]
splot "binary3" binary

Click here for minimal script to generate this plot
