gnuplot demo script: columnhead.dem

autogenerated by webify.pl on Sat Mar 11 15:38:21 2023
gnuplot version gnuplot 5.4 patchlevel 7alpha
#
# - Demonstrates use of columnhead(N) in a using specifier.
# - Demonstrates delayed evaluation of columnhead(N) in plot title
# - Demonstrates failure of 5.0 and 5.2.0 to terminate open-ended iteration
#   at the front of a plot command.
#

$DATA << EOD
aA	bB	cC	dD
4	8	6	7
8	5	7	3
3	8	4	6
1	2	9	10
EOD

set key box autotitle columnhead width 2 samplen 0
set key title "Columns"
set offset 1,1,1,1
set xlabel "Line in data file"
set ylabel "Column values"
set title "Point labels show which column they came from"
set xtics 1,1,4 format "line %.0g"

plot for [col=1:*] $DATA using (1+$0):(column(col)):(columnhead(col)[2:2]) with labels title columnhead(col)[2:2]
