gnuplot demo script: parallel.dem

autogenerated by webify.pl on Sat Mar 11 15:38:57 2023
gnuplot version gnuplot 5.4 patchlevel 7alpha
#
# Parallel axis plot
# shows plot layout but would better use some real data set
# NB: March 2019 revised syntax for 5.3
#
set title "Parallel Axis Plot" font ",15"

set border 0
unset key
set xrange [] noextend
unset ytics
set style data parallelaxes

# Use x-axis tic positions to label the axes
set xtics 1,1,5 format "axis %g" scale 0,0

# Turn on axis tics for the parallel axes
set for [i=1:5] paxis i tics

# Use the range commands to create an "interesting" plot.
# For suitable input data this is the sort of result you
# might get without axis range manipulation.

set paxis 2 range  [0:30]
set paxis 4 range  [-10:50]
set paxis 5 range  [50:*] reverse
set paxis 5 tics left offset 4

plot 'silver.dat' using 2:(int($0/25)) lc variable, '' using 3, '' using 1, '' using ($3/2), '' using 2


Click here for minimal script to generate this plot





set title "Parallel Axis Plot" font ",15"

save_encoding = GPVAL_ENCODING
set encoding utf8

set border 0
unset ytics
set xrange [] noextend
unset key

set style data parallelaxes
set paxis 1 tics format '%.0f Å' offset -1
set paxis 4 tics left offset 4 format '%.0f Å^2'
set paxis 4 range [0:40]

plot 'GM1_sugar.pdb' using 6:5 lc var lw 2 title "X", '' using 7 at 1.75 title "Y", '' using 8 at 2.5 title "Z", '' using 10 title "B"


Click here for minimal script to generate this plot




set style data parallel
set palette defined (0 "dark-blue", 1 "dark-orange")
set xrange [0.5:7.5]
unset ytics
set xtics font ":Bold,13"
unset border
set bmargin 4
unset colorbox
a = 12.
b = 34.

set title "Parallel Axis Plot" font ",15"

plot sample [x=1:20] '+' using (rand(0)):0 lc palette title "random", \
    '' u ($1) title "x", \
    '' u (-$1) title "-x", \
    '' u (a*$1) title "a*x", \
    '' u (a*$1+b) title "a*x+b", \
    '' u (exp($1)) title "e^x", \
    '' u (1/$1) title "1/x"


Click here for minimal script to generate this plot




set encoding save_encoding
