# Calculate solar path in horizontal coordinates (altitude, azimuth)
# Use gnuplot's polar mode with inverted R range so that the horizon
# (altitude 0°) is at the perimeter and altitude 90° is at the center.
#
save_encoding = GPVAL_ENCODING
set encoding utf8
set label 1 at screen 0.02, 0.95 font ":Bold,10"
set label 1 "Solar path at\nLatitude 47.67 N"
set timestamp "Seattle - %d %b %Y" offset 1,1
# Set up equations for Azimuth(t) and Altitude(t) as a function of
# t = seconds before or after solar noon on the day of interest
# at a particular latitude.
# Here we calculate for Seattle (47.67 N -122.28 W)
Latitude = 47.67
Longitude = -122.28
Date = "21-12-2016"
call 'solar_params.dem'
array dummy[150]
array winter_alt[150]; array winter_azi[150]
time = -12 * Hour
do for [t = 1 : 150] {
winter_alt[t] = Altitude(time)
winter_azi[t] = Azimuth(time)
time = time + 10 * Minute
}
print Date, " sunrise ", sunrise, " sunset ", sunset, " sunlight ", sunlight
Date = "22-06-2017"
call 'solar_params.dem'
array summer_alt[150]; array summer_azi[150]
time = -12 * Hour
do for [t = 1 : 150] {
summer_alt[t] = Altitude(time)
summer_azi[t] = Azimuth(time)
time = time + 10 * Minute
}
print Date, " sunrise ", sunrise, " sunset ", sunset, " sunlight ", sunlight
Date = strftime("%d-%m-%Y",time(0) + Day*Longitude/360.)
call 'solar_params.dem'
array today_alt[150]; array today_azi[150]
time = -12 * Hour
do for [t = 1 : 150] {
today_alt[t] = Altitude(time)
today_azi[t] = Azimuth(time)
dummy[t] = time
time = time + 10 * Minute
}
print Date, " sunrise ", sunrise, " sunset ", sunset, " sunlight ", sunlight
today = "Today ☉ \n".sunlight."\nof sunlight"
#
set angle degrees
set polar
set grid polar
unset xtics
unset ytics
unset border
unset key
set size square
set rrange [90:0]
set ttics add ("N" 0, "E" 90, "S" 180, "W" -90) font ":Bold"
set rtics format "%.0f°"
set rtics 30
set rlabel "Altitude" offset -2 font ":Bold"
set border polar
set style data lines
# By convention North (azimuth 0°) is at the top with angles increasing clockwise
set theta top clockwise
plot dummy using (winter_azi[$1]):(winter_alt[$1]) lw 2 title " Winter Solstice" at beg left, \
dummy using (summer_azi[$1]):(summer_alt[$1]) lw 2 title " Summer Solstice" at beg left, \
dummy using (today_azi[$1]):(today_alt[$1]) lw 2 title today at end right
Click here for minimal script to generate this plot
