gnuplot demo script: unicode.dem

autogenerated by webify.pl on Fri Dec 20 14:48:04 2024
gnuplot version gnuplot 6.0 patchlevel 2
#
# Exercise use of unicode escape sequences (not yet supported by all terminals)
#
set border 0
unset tics

set title "Illustrate use of unicode escape sequences" font "serif,15"

set label 1 at screen 0.1, screen 0.8 font "serif,15"
set label 2 at screen 0.1, screen 0.7 font "serif,15"
set label 3 at screen 0.1, screen 0.6 font "serif,15"
set label 4 at screen 0.1, screen 0.5 font "serif,15"
set label 5 at screen 0.1, screen 0.4 font "serif,15"
set label 6 at screen 0.1, screen 0.3 font "serif,15"
set label 7 at screen 0.1, screen 0.2 font "serif,15"

set label 1 "unicode {\\\\}U+221E : \U+221E   Infinity"
set label 2 "unicode {\\\\}U+210F : \U+210F   Planck constant h-bar"
set label 3 "unicode {\\\\}U+222C : \U+222C   Double integral"
set label 4 "unicode {\\\\}U+03F5 : \U+03F5   Greek lunate epsilon"
set label 5 "unicode {\\\\}U+7403 : \U+7403   CJK unified ideograph 'sphere'"
set label 6 "\\{a{\\\\}U+0361\\}b        : {a\U+0361}b   Ligature tie (combining)"
set label 7 "v{\\\\}U+20D7           : v\U+20D7    Combining right arrow above"

plot [0:1][0:1] -1 notitle


Click here for minimal script to generate this plot
