gnuplot demo script: complex_airy.dem

autogenerated by webify.pl on Wed Aug 21 21:31:28 2024
gnuplot version gnuplot 6.1 last modified 2024-08-21
#
# Exercise complex Airy functions Ai(z), Bi(z)
#
if (!strstrt(GPVAL_COMPILE_OPTIONS, "+AMOS")) {
    print "This copy of gnuplot does not support Ai, Bi"
    exit  # return to caller
}

#
# Compare built-in airy(x) with AMOS Ai(z) for real z
#
set xrange [0:5]

set multiplot layout 2,1 \
    title "Agreement of built-in airy(x) with Amos library Ai(z) for real z"
set lmargin at screen 0.15
plot [0:10] abs(Ai(x) - airy(x)) / Ai(x)
set yrange [0:1.4]
set ytics 1
plot [0:30] (Ai(x) - airy(x)) / Ai(x)
unset multiplot


Click here for minimal script to generate this plot





set xrange [-4:4]
set yrange [-4:4]
set zrange [-4:2]
set sample 51
set isosample 51
set view 45, 51, 0.9
set xyplane 0
set border -1
set pm3d border lt -1 lighting spec 0.5
set cblabel "arg(Ai(x + iy))" rotate
unset cbtics
set xlabel "x"
set ylabel "iy"
set palette defined (0 "dark-red", 1 "gold")

set title "{/Times:Italic=16 Real( Ai(x+iy) )}"
set title offset 0,0.5
splot '++' using 1:2:(real(Ai(x + y*I))):(arg(Ai(x + y*I))) notitle with pm3d


Click here for minimal script to generate this plot




set title "{/Times:Italic=16 Imag( Ai(x+iy) )}"
set title offset 0,0.5
splot '++' using 1:2:(imag(Ai(x + y*I))):(arg(Ai(x + y*I))) notitle with pm3d


Click here for minimal script to generate this plot




save_encoding = GPVAL_ENCODING
set encoding utf8
set log cb
set cbtics format "%.0t×10^{%T}"
unset mcbtics
set palette cubehelix gamma 2.0
set view map scale 0.9
set isosamples 100,100

set title 'Modulus of Ai(z)'
splot abs(Ai( x + y*{0,1} )) with pm3d

Click here for minimal script to generate this plot




set title 'Modulus of Bi(z)'
splot abs(Bi( x + y*{0,1} )) with pm3d

Click here for minimal script to generate this plot




set encoding save_encoding
