gnuplot demo script: poldat.dem

autogenerated by webify.pl on Wed Aug 21 21:28:39 2024
gnuplot version gnuplot 6.1 last modified 2024-08-21
set size square
set timestamp "%a %d %b %Y"
set clip
set xtics axis nomirror
set ytics axis nomirror
unset grid
unset polar
set title "Primitive Smith Chart"
unset key
set xlabel "Impedance or Admittance Coordinates"
set para
set rrange [-0 : 10]
set trange [-pi : pi]
set xrange [-1:1]
set yrange [-1:1]
tv(t,r) = sin(t)/(1+r)
tu(t,r) = (cos(t) +r)/(1+r)
cu(t,x) = 1 + cos(t)/x
cv(t,x) = (1+ sin(t))/x
plot cu(t,.1),cv(t,.1),cu(t,.1),-cv(t,.1),\
cu(t,1),cv(t,1),cu(t,1),-cv(t,1),\
cu(t,10),cv(t,10),cu(t,10),-cv(t,10),\
tu(t,.1),tv(t,.1),\
tu(t,.5),tv(t,.5),\
tu(t,1),tv(t,1),\
tu(t,5),tv(t,5),\
tu(t,10),tv(t,10),\
cu(t,.5),cv(t,.5),cu(t,.5),-cv(t,.5),\
tu(t,0),tv(t,0)


Click here for minimal script to generate this plot




set angles degrees
set polar
set grid polar 15. lt -1 dt 0 lw 0.5
unset border
unset param
set title "Antenna Pattern"
set xlabel "Azimuth"
set ylabel "dBSM"
set style data line
set rrange [-200:60]
set trange [*:*]
set xrange [-220:220]
set yrange [-220:220]
unset xtics
plot "antenna.dat" index 0 using 1:5, "" index 1


Click here for minimal script to generate this plot





set polar
set angle degree
set grid polar 15. lt -1 dt 0 lw 0.5
set border 0
set logscale r 10
set view equal xy
set size square
set noxtics
set noytics
set rrange [.5 : 19]
set trange [90 : 360]
set rtics axis scale 0.5,0 nomirror rotate by -270  offset 0, 0.7
set rtics (2,5,10,15)
set key opaque box samplen 0.75
set title "log scale polar axis, trange in degrees"
#
set style data impulse
plot 'silver.dat' using ($1*1.8/pi):3:0 lc var lw 2 title 'silver.dat'


Click here for minimal script to generate this plot





set title "yerrors in polar mode"

$DATA << EOD
0   1.3 0.2
30  0.9 0.1
60  0.7 0.1
90  1.0 0.3
120 1.1 0.1
150 0.5 0.1
180 1.2 0.2
EOD

set polar
set angles degrees
set grid polar 15. lt -1 dt 0 lw 0.5
unset border
unset xtics
unset ytics
unset raxis
set yrange [0:1.5]
set size ratio 0.5

plot $DATA with yerrorbars lw 1.5 title "polar error bars"


Click here for minimal script to generate this plot
