gnuplot demo script: zerror.dem

autogenerated by webify.pl on Wed Aug 21 21:29:18 2024
gnuplot version gnuplot 6.1 last modified 2024-08-21
#
# zerrorfill
#
set yrange [0.5:5.5]
set zrange [1:*]
set xyplane at 1
set log z
set key opaque box height 1 at screen .9, .8
set border 127
set grid x y z vertical
set grid lt 1 lw 0.75 lc "grey"
set xtics offset 0, -0.5
set ytics offset -0.5, -0.5

set title "splot with zerrorfill\n(note that plot ordering must be back-to-front)"
splot for [k=5:1:-1] 'silver.dat' using 1:(k):2:3 with zerror lt black fc lt k title "k = ".k


Click here for minimal script to generate this plot



#
# Reproduce surface1.dem plot #16
# using zerrorfill instead of hidden3d parametric surfaces
#
set format z "%.1f"
unset key
set view 66, 200, 1, 1
set xyplane 0
unset xtics
unset ytics
set title "fence plot constructed with zerrorfill"
set xlabel "X axis"  rotate parallel
set ylabel "Y axis" rotate parallel offset -4
set pm3d depthorder base
sinc(u,v) = sin(sqrt(u**2+v**2)) / sqrt(u**2+v**2)

set style fill solid noborder
splot for [i=-5:4][y=-50:50:5] '+' using (i):($1/100.):(-1):(-1):(sinc($1/10., 1.+i)) with zerrorfill


Click here for minimal script to generate this plot
